VISTA701I
Insert · 10 kW
Finish: BLACK
- 10-year warranty 5+5 on cast iron body
- 83% efficiency High seasonal efficiency rating
- 20-year parts Spare parts guarantee
Insert
A Vista i built-in fireplace uses today's most refined combustion techniques, to transform any existing open fireplace into a more environmentally friendly closed fireplace. For the interior lining you have the choice between slat-shaped cast iron or vermiculite stones. The finishing touch is a 4 mm or 25 mm frame.
-
01
Triple-pass smoke chamber
Combustion gases travel a longer path through the body, extracting heat that would otherwise escape up the chimney.
-
02
Air-wash glass system
A laminar curtain of pre-heated air sweeps the inside of the glass, keeping the view clear through the entire burn cycle.
-
03
Direct outside-air option
Sealed combustion intake (Ø80 mm) for installation in passive houses and low-energy buildings without affecting interior air quality.
-
04
Cast iron throughout
Body, baffle, ash floor and door frame all cast in our Weelde foundry from a 70% recycled iron alloy.
Specifications
- Article
- 01.93516.121
- Trade code
- VISTA701I/V2
- Dimensions (mm)
- 690x490x440
- Weight
- 95 kg
- Fuel
- Wood
- Connection diameter
- 150 mm
- Connection placement
- Top
- Nominal performance
- 10 kW
- Efficiency
- 83,00%
- Seasonal efficiency
- 72,25
- CO emissions
- 0,08
- NOx emissions
- 112,00
- Dust
- 19,00
- Log length
- 50 cm
- Flue gas volume
- 7,10
- Min draught
- 13
- Energy class
- 109,60
- Energy index
- A+
- Clearance front
- 1200 mm
- Clearance rear
- 50 mm
- Clearance side
- 50 mm
Documents & PDFs
All technical documents for the VISTA701I — versioned and date-stamped. Older versions remain available for stoves under previous certification.
Installation
The VISTA701I must be installed by a certified professional. The +5 year warranty extension on the cast iron body is contingent on certified installation and registration within 60 days.
Installation guides
Ten years on cast iron.
The VISTA701I is covered by the DOVRE 5+5 warranty programme — the longest warranty in the European cast-iron heating market.
